Property Validation Examples

This page provides comprehensive examples of Property Validation scripts for various business scenarios. Each example includes complete code, configuration steps, and testing approaches.

Example 1: Email Validation with Domain Restrictions

Scenario: Validate email format and restrict to specific company domains.

Script Implementation

DECLARE
  c_script_name CONSTANT VARCHAR2(100) := 'VALIDATE_CORPORATE_EMAIL';
  c_email_pattern CONSTANT VARCHAR2(200) :=
    '^[A-Za-z0-9._%+-]+@[A-Za-z0-9.-]+\.[A-Za-z]{2,}$';
  l_domain VARCHAR2(100);
  l_valid_domains VARCHAR2(500) := 'company.com,company.co.uk,subsidiary.com';

  PROCEDURE log(p_msg VARCHAR2) IS
  BEGIN
    ew_debug.log(p_text      => p_msg,
                 p_source_ref => c_script_name);
  END;

BEGIN
  -- Initialize
  ew_lb_api.g_status := ew_lb_api.g_success;
  ew_lb_api.g_message := NULL;

  -- Allow NULL (unless required elsewhere)
  IF ew_lb_api.g_prop_value IS NULL THEN
    RETURN;
  END IF;

  log('Validating email: ' || ew_lb_api.g_prop_value);

  -- Check basic email format
  IF NOT REGEXP_LIKE(LOWER(ew_lb_api.g_prop_value), c_email_pattern) THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Invalid email format. Example: user@company.com';
    RETURN;
  END IF;

  -- Extract domain
  l_domain := LOWER(SUBSTR(ew_lb_api.g_prop_value,
                           INSTR(ew_lb_api.g_prop_value, '@') + 1));

  -- Check if domain is in allowed list
  IF INSTR(l_valid_domains, l_domain) = 0 THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Email must use company domain: ' ||
                            REPLACE(l_valid_domains, ',', ', ');
    log('Invalid domain: ' || l_domain);
    RETURN;
  END IF;

  -- Additional validation: Check for consecutive dots
  IF INSTR(ew_lb_api.g_prop_value, '..') > 0 THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Email cannot contain consecutive dots';
    RETURN;
  END IF;

  log('Email validation passed');

EXCEPTION
  WHEN OTHERS THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Email validation error: ' || SQLERRM;
    log('Error: ' || SQLERRM);
END;

Test Cases

Input	Expected Result
john.doe@company.com	Pass
user@subsidiary.com	Pass
user@external.com	Fail - Invalid domain
invalid.email	Fail - Missing @
user..name@company.com	Fail - Consecutive dots

Example 2: Hierarchical Code Validation

Scenario: Validate member codes based on their position in hierarchy.

Script Implementation

DECLARE
  c_script_name CONSTANT VARCHAR2(100) := 'VALIDATE_HIERARCHICAL_CODE';
  l_level NUMBER;
  l_parent_code VARCHAR2(50);
  l_expected_prefix VARCHAR2(20);
  l_code_pattern VARCHAR2(100);

  PROCEDURE log(p_msg VARCHAR2) IS
  BEGIN
    ew_debug.log(p_text      => p_msg,
                 p_source_ref => c_script_name);
  END;

BEGIN
  -- Initialize
  ew_lb_api.g_status := ew_lb_api.g_success;
  ew_lb_api.g_message := NULL;

  -- Only validate for Code property
  IF ew_lb_api.g_prop_name != 'Member_Code' THEN
    RETURN;
  END IF;

  log('Validating code: ' || ew_lb_api.g_prop_value ||
      ' for member: ' || ew_lb_api.g_member_name);

  -- Get member level
  l_level := ew_statistics.get_level(
    p_app_dimension_id => ew_lb_api.g_app_dimension_id,
    p_member_id       => ew_lb_api.g_member_id
  );

  -- Get parent code if not root
  IF ew_lb_api.g_parent_member_name IS NOT NULL THEN
    l_parent_code := ew_hierarchy.get_member_prop_value(
      p_app_name    => ew_lb_api.g_app_name,
      p_dim_name    => ew_lb_api.g_dim_name,
      p_member_name => ew_lb_api.g_parent_member_name,
      p_prop_label  => 'Member_Code'
    );
  END IF;

  -- Define validation rules by level
  CASE l_level
    WHEN 0 THEN
      -- Base level: Must start with parent code
      IF l_parent_code IS NOT NULL THEN
        l_expected_prefix := l_parent_code || '.';
        IF SUBSTR(ew_lb_api.g_prop_value, 1, LENGTH(l_expected_prefix))
           != l_expected_prefix THEN
          ew_lb_api.g_status := ew_lb_api.g_error;
          ew_lb_api.g_message := 'Code must start with parent code: ' ||
                                  l_expected_prefix;
        END IF;
      END IF;

    WHEN 1 THEN
      -- Level 1: Format XXX.YYY
      l_code_pattern := '^[A-Z]{3}\.[0-9]{3}$';
      IF NOT REGEXP_LIKE(ew_lb_api.g_prop_value, l_code_pattern) THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Level 1 code format: XXX.YYY (e.g., FIN.001)';
      END IF;

    WHEN 2 THEN
      -- Level 2: Format XXX
      l_code_pattern := '^[A-Z]{3}$';
      IF NOT REGEXP_LIKE(ew_lb_api.g_prop_value, l_code_pattern) THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Level 2 code format: XXX (e.g., FIN)';
      END IF;

    ELSE
      -- Root level: No restrictions
      NULL;
  END CASE;

  -- Check uniqueness within parent
  IF ew_lb_api.g_status = ew_lb_api.g_success THEN
    DECLARE
      l_count NUMBER;
    BEGIN
      SELECT COUNT(*)
      INTO l_count
      FROM ew_member_properties p
      JOIN ew_hierarchy_members h ON p.member_id = h.member_id
      WHERE p.app_dimension_id = ew_lb_api.g_app_dimension_id
      AND p.prop_name = 'Member_Code'
      AND p.prop_value = ew_lb_api.g_prop_value
      AND h.parent_id = (SELECT parent_id
                         FROM ew_hierarchy_members
                         WHERE member_id = ew_lb_api.g_member_id)
      AND p.member_id != ew_lb_api.g_member_id;

      IF l_count > 0 THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Code already exists under this parent';
      END IF;
    END;
  END IF;

  log('Validation result: ' || ew_lb_api.g_status);

EXCEPTION
  WHEN OTHERS THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Code validation error: ' || SQLERRM;
    log('Error: ' || SQLERRM);
END;

Example 3: Cross-Field Date Validation

Scenario: Validate date relationships and business rules across multiple date fields.

Script Implementation

DECLARE
  c_script_name CONSTANT VARCHAR2(100) := 'VALIDATE_DATE_RELATIONSHIPS';
  l_start_date DATE;
  l_end_date DATE;
  l_review_date DATE;
  l_current_date DATE := TRUNC(SYSDATE);
  l_date_format CONSTANT VARCHAR2(20) := 'MM/DD/YYYY';

  PROCEDURE log(p_msg VARCHAR2) IS
  BEGIN
    ew_debug.log(p_text      => p_msg,
                 p_source_ref => c_script_name);
  END;

  FUNCTION get_date_prop(p_prop_name VARCHAR2) RETURN DATE IS
    l_value VARCHAR2(50);
  BEGIN
    l_value := ew_hierarchy.get_member_prop_value(
      p_app_name    => ew_lb_api.g_app_name,
      p_dim_name    => ew_lb_api.g_dim_name,
      p_member_name => ew_lb_api.g_member_name,
      p_prop_label  => p_prop_name
    );

    IF l_value IS NOT NULL THEN
      RETURN TO_DATE(l_value, l_date_format);
    END IF;

    RETURN NULL;
  EXCEPTION
    WHEN OTHERS THEN
      RETURN NULL;
  END;

BEGIN
  -- Initialize
  ew_lb_api.g_status := ew_lb_api.g_success;
  ew_lb_api.g_message := NULL;

  -- Only validate date properties
  IF ew_lb_api.g_prop_name NOT IN ('Start_Date', 'End_Date', 'Review_Date') THEN
    RETURN;
  END IF;

  log('Validating date: ' || ew_lb_api.g_prop_name ||
      ' = ' || ew_lb_api.g_prop_value);

  -- First, validate date format
  BEGIN
    l_current_date := TO_DATE(ew_lb_api.g_prop_value, l_date_format);
  EXCEPTION
    WHEN OTHERS THEN
      ew_lb_api.g_status := ew_lb_api.g_error;
      ew_lb_api.g_message := 'Invalid date format. Use MM/DD/YYYY';
      RETURN;
  END;

  -- Get related dates
  l_start_date := get_date_prop('Start_Date');
  l_end_date := get_date_prop('End_Date');
  l_review_date := get_date_prop('Review_Date');

  -- Apply validation rules based on property
  CASE ew_lb_api.g_prop_name
    WHEN 'Start_Date' THEN
      l_start_date := TO_DATE(ew_lb_api.g_prop_value, l_date_format);

      -- Start date cannot be in the past (more than 30 days)
      IF l_start_date < l_current_date - 30 THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Start date cannot be more than 30 days in the past';
      END IF;

      -- If end date exists, start must be before end
      IF l_end_date IS NOT NULL AND l_start_date > l_end_date THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Start date must be before end date';
      END IF;

    WHEN 'End_Date' THEN
      l_end_date := TO_DATE(ew_lb_api.g_prop_value, l_date_format);

      -- End date must be after start date
      IF l_start_date IS NOT NULL AND l_end_date < l_start_date THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'End date must be after start date ' ||
                                TO_CHAR(l_start_date, l_date_format);
      END IF;

      -- End date cannot be more than 5 years in future
      IF l_end_date > ADD_MONTHS(l_current_date, 60) THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'End date cannot be more than 5 years in the future';
      END IF;

    WHEN 'Review_Date' THEN
      l_review_date := TO_DATE(ew_lb_api.g_prop_value, l_date_format);

      -- Review date must be between start and end
      IF l_start_date IS NOT NULL AND l_review_date < l_start_date THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Review date must be after start date';
      END IF;

      IF l_end_date IS NOT NULL AND l_review_date > l_end_date THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Review date must be before end date';
      END IF;

      -- Review date must be in the future
      IF l_review_date <= l_current_date THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Review date must be in the future';
      END IF;
  END CASE;

  log('Date validation result: ' || ew_lb_api.g_status);

EXCEPTION
  WHEN OTHERS THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Date validation error: ' || SQLERRM;
    log('Error: ' || SQLERRM);
END;

Example 4: Percentage Allocation Validation

Scenario: Ensure percentage allocations across related members sum to 100%.

Script Implementation

DECLARE
  c_script_name CONSTANT VARCHAR2(100) := 'VALIDATE_PERCENTAGE_ALLOCATION';
  l_current_value NUMBER;
  l_total_allocation NUMBER;
  l_sibling_count NUMBER;

  PROCEDURE log(p_msg VARCHAR2) IS
  BEGIN
    ew_debug.log(p_text      => p_msg,
                 p_source_ref => c_script_name);
  END;

BEGIN
  -- Initialize
  ew_lb_api.g_status := ew_lb_api.g_success;
  ew_lb_api.g_message := NULL;

  -- Only validate percentage properties
  IF ew_lb_api.g_prop_name NOT IN ('Allocation_Percent', 'Ownership_Percent') THEN
    RETURN;
  END IF;

  log('Validating percentage: ' || ew_lb_api.g_prop_value);

  -- Validate numeric value
  BEGIN
    l_current_value := TO_NUMBER(ew_lb_api.g_prop_value);
  EXCEPTION
    WHEN VALUE_ERROR THEN
      ew_lb_api.g_status := ew_lb_api.g_error;
      ew_lb_api.g_message := 'Percentage must be a valid number';
      RETURN;
  END;

  -- Check range 0-100
  IF l_current_value < 0 OR l_current_value > 100 THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Percentage must be between 0 and 100';
    RETURN;
  END IF;

  -- Check precision (max 2 decimal places)
  IF l_current_value != ROUND(l_current_value, 2) THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Maximum 2 decimal places allowed';
    RETURN;
  END IF;

  -- Calculate total allocation among siblings
  BEGIN
    SELECT SUM(TO_NUMBER(p.prop_value)) -
           NVL(TO_NUMBER(ew_lb_api.g_old_prop_value), 0) +
           l_current_value,
           COUNT(DISTINCT h.member_id)
    INTO l_total_allocation, l_sibling_count
    FROM ew_hierarchy_members h
    JOIN ew_member_properties p ON h.member_id = p.member_id
    WHERE h.parent_id = (SELECT parent_id
                         FROM ew_hierarchy_members
                         WHERE member_id = ew_lb_api.g_member_id)
    AND p.prop_name = ew_lb_api.g_prop_name
    AND p.app_dimension_id = ew_lb_api.g_app_dimension_id;

    log('Total allocation: ' || l_total_allocation ||
        ' across ' || l_sibling_count || ' siblings');

    -- Allow slight variance for rounding (0.01%)
    IF l_total_allocation > 100.01 THEN
      ew_lb_api.g_status := ew_lb_api.g_error;
      ew_lb_api.g_message := 'Total allocation exceeds 100% (Current total: ' ||
                              ROUND(l_total_allocation, 2) || '%)';
    END IF;

    -- Warning if not equal to 100 (but don't block)
    IF l_sibling_count > 1 AND
       ABS(l_total_allocation - 100) > 0.01 AND
       l_total_allocation <= 100 THEN
      -- Could set warning status if supported
      log('Warning: Total allocation is ' || ROUND(l_total_allocation, 2) || '%');
    END IF;

  EXCEPTION
    WHEN OTHERS THEN
      log('Error calculating total: ' || SQLERRM);
  END;

EXCEPTION
  WHEN OTHERS THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Percentage validation error: ' || SQLERRM;
    log('Error: ' || SQLERRM);
END;

Example 5: Complex Business Rule Validation

Scenario: Validate cost center attributes based on complex business rules.

Script Implementation

DECLARE
  c_script_name CONSTANT VARCHAR2(100) := 'VALIDATE_COST_CENTER_RULES';
  l_cc_type VARCHAR2(50);
  l_region VARCHAR2(50);
  l_budget NUMBER;
  l_headcount NUMBER;
  l_status VARCHAR2(20);

  PROCEDURE log(p_msg VARCHAR2) IS
  BEGIN
    ew_debug.log(p_text      => p_msg,
                 p_source_ref => c_script_name);
  END;

  FUNCTION get_prop(p_name VARCHAR2) RETURN VARCHAR2 IS
  BEGIN
    RETURN ew_hierarchy.get_member_prop_value(
      p_app_name    => ew_lb_api.g_app_name,
      p_dim_name    => ew_lb_api.g_dim_name,
      p_member_name => ew_lb_api.g_member_name,
      p_prop_label  => p_name
    );
  END;

  PROCEDURE validate_budget_rules IS
  BEGIN
    l_budget := TO_NUMBER(get_prop('Budget'));
    l_headcount := TO_NUMBER(get_prop('Headcount'));
    l_cc_type := get_prop('CC_Type');

    -- Rule 1: Admin cost centers limited budget
    IF l_cc_type = 'Administrative' AND l_budget > 500000 THEN
      ew_lb_api.g_status := ew_lb_api.g_error;
      ew_lb_api.g_message := 'Administrative cost centers cannot exceed $500,000 budget';
      RETURN;
    END IF;

    -- Rule 2: Budget per headcount ratios
    IF l_headcount > 0 THEN
      DECLARE
        l_per_head NUMBER := l_budget / l_headcount;
      BEGIN
        IF l_cc_type = 'Production' AND l_per_head < 50000 THEN
          ew_lb_api.g_status := ew_lb_api.g_error;
          ew_lb_api.g_message := 'Production cost centers require minimum $50,000 per headcount';
        ELSIF l_cc_type = 'Sales' AND l_per_head < 75000 THEN
          ew_lb_api.g_status := ew_lb_api.g_error;
          ew_lb_api.g_message := 'Sales cost centers require minimum $75,000 per headcount';
        END IF;
      END;
    END IF;
  END;

  PROCEDURE validate_regional_rules IS
  BEGIN
    l_region := get_prop('Region');
    l_status := get_prop('Status');

    -- Rule: Certain regions require additional approval
    IF l_region IN ('EMEA', 'APAC') AND
       ew_lb_api.g_prop_name = 'Status' AND
       ew_lb_api.g_prop_value = 'Active' THEN

      -- Check for approval flag
      IF NVL(get_prop('Regional_Approval'), 'N') != 'Y' THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'EMEA/APAC cost centers require regional approval before activation';
      END IF;
    END IF;
  END;

  PROCEDURE validate_manager_assignment IS
    l_manager VARCHAR2(100);
    l_manager_count NUMBER;
  BEGIN
    IF ew_lb_api.g_prop_name = 'Manager' THEN
      l_manager := ew_lb_api.g_prop_value;

      -- Check manager workload
      SELECT COUNT(*)
      INTO l_manager_count
      FROM ew_member_properties
      WHERE app_dimension_id = ew_lb_api.g_app_dimension_id
      AND prop_name = 'Manager'
      AND prop_value = l_manager
      AND member_id != ew_lb_api.g_member_id;

      IF l_manager_count >= 10 THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Manager ' || l_manager ||
                                ' already manages 10 cost centers (maximum allowed)';
      END IF;
    END IF;
  END;

BEGIN
  -- Initialize
  ew_lb_api.g_status := ew_lb_api.g_success;
  ew_lb_api.g_message := NULL;

  -- Only validate for cost center members
  IF NOT (ew_lb_api.g_member_name LIKE 'CC_%' OR
          ew_lb_api.g_member_name LIKE 'COST_%') THEN
    RETURN;
  END IF;

  log('Validating business rules for: ' || ew_lb_api.g_member_name ||
      '.' || ew_lb_api.g_prop_name);

  -- Apply different validations based on property
  CASE ew_lb_api.g_prop_name
    WHEN 'Budget' THEN
      validate_budget_rules();

    WHEN 'Status' THEN
      validate_regional_rules();

    WHEN 'Manager' THEN
      validate_manager_assignment();

    WHEN 'CC_Type' THEN
      -- Validate against allowed values
      IF ew_lb_api.g_prop_value NOT IN
         ('Administrative', 'Production', 'Sales', 'Support', 'Research') THEN
        ew_lb_api.g_status := ew_lb_api.g_error;
        ew_lb_api.g_message := 'Invalid cost center type';
      END IF;

    ELSE
      NULL; -- No validation for other properties
  END CASE;

  log('Business rule validation result: ' || ew_lb_api.g_status);

EXCEPTION
  WHEN OTHERS THEN
    ew_lb_api.g_status := ew_lb_api.g_error;
    ew_lb_api.g_message := 'Business rule validation error: ' || SQLERRM;
    log('Error: ' || SQLERRM);
END;

Testing Framework

Automated Test Suite

CREATE OR REPLACE PROCEDURE test_property_validations IS
  PROCEDURE run_test(
    p_test_name VARCHAR2,
    p_prop_name VARCHAR2,
    p_prop_value VARCHAR2,
    p_expected_status VARCHAR2,
    p_expected_msg_pattern VARCHAR2 DEFAULT NULL
  ) IS
  BEGIN
    -- Set context
    ew_lb_api.g_prop_name := p_prop_name;
    ew_lb_api.g_prop_value := p_prop_value;
    ew_lb_api.g_member_name := 'TEST_MEMBER';

    -- Execute validation
    -- (Call appropriate validation script)

    -- Check results
    IF ew_lb_api.g_status = p_expected_status THEN
      DBMS_OUTPUT.PUT_LINE('✓ PASS: ' || p_test_name);
    ELSE
      DBMS_OUTPUT.PUT_LINE('✗ FAIL: ' || p_test_name);
      DBMS_OUTPUT.PUT_LINE('  Expected: ' || p_expected_status);
      DBMS_OUTPUT.PUT_LINE('  Actual: ' || ew_lb_api.g_status);
    END IF;

    -- Check error message pattern if provided
    IF p_expected_msg_pattern IS NOT NULL AND
       ew_lb_api.g_message NOT LIKE p_expected_msg_pattern THEN
      DBMS_OUTPUT.PUT_LINE('  Message mismatch: ' || ew_lb_api.g_message);
    END IF;
  END;

BEGIN
  DBMS_OUTPUT.PUT_LINE('=== Running Property Validation Tests ===');

  -- Email validation tests
  run_test('Valid email', 'Email', 'user@company.com', 'S');
  run_test('Invalid email - no @', 'Email', 'usercompany.com', 'E', '%@%');
  run_test('Invalid domain', 'Email', 'user@external.com', 'E', '%domain%');

  -- Date validation tests
  run_test('Valid start date', 'Start_Date', TO_CHAR(SYSDATE+10, 'MM/DD/YYYY'), 'S');
  run_test('Past start date', 'Start_Date', '01/01/2000', 'E', '%past%');

  -- Percentage tests
  run_test('Valid percentage', 'Allocation_Percent', '25.5', 'S');
  run_test('Over 100%', 'Allocation_Percent', '101', 'E', '%100%');
  run_test('Negative percentage', 'Allocation_Percent', '-5', 'E', '%0%');

  DBMS_OUTPUT.PUT_LINE('=== Tests Complete ===');
END;

Performance Considerations

Optimization Techniques

Cache Frequently Used Data

-- Package variable for caching
g_cached_values VARCHAR2(4000);

-- Load once per session
IF g_cached_values IS NULL THEN
  SELECT LISTAGG(code, ',') WITHIN GROUP (ORDER BY code)
  INTO g_cached_values
  FROM valid_codes
  WHERE active = 'Y';
END IF;

Minimize Database Calls

-- Bad: Multiple queries
FOR i IN 1..10 LOOP
  SELECT ... INTO ... WHERE id = i;
END LOOP;

-- Good: Single query
SELECT ... BULK COLLECT INTO ... WHERE id IN (1,2,3...10);

Use Appropriate Validation Timing

-- Real-time (keystroke): Simple checks only
IF LENGTH(value) > 50 THEN error; END IF;

-- On field exit: Moderate complexity
validate_format(value);

-- On save: Complex validations
validate_cross_field_rules();

Best Practices Summary

User Experience
Provide clear, actionable error messages
Include examples in error text
Validate progressively (simple to complex)
Performance
Cache static data
Optimize queries
Consider validation timing
Maintainability
Use constants for patterns
Log validation attempts
Document business rules
Testing
Test all validation paths
Include edge cases
Verify error messages

Next Steps

Standard Validations - Built-in validation types
API Reference - Supporting functions
Property Derivations - Related derivation scripts

Performance Note

Remember that validation scripts execute on every keystroke for real-time validation. Keep the logic lightweight and optimize database queries to maintain UI responsiveness.
